Semi-reboque baixa novo FGM 32 BREAKDOWN SERVICE/ TRUCK TRANSPORTER EXTENDABLE

SEMITRAILER BREAKDOWN SERVICE 3 AXLES PNEUMATIC WITH EXTENDABLE FRAME

MODEL: FGM 32L 135 – 3 A

AREAS OF USE: ROAD ASSISTANCE, TRACK-GUIDED VEHICLES (TRAMS, LOCOMOTIVES, BUSES), TRUCK TRANSPORTER

o N.3 pneumatic axels, ROR make

o 2nd & 3rd axle self-steering

o Extendable loading platform from gooseneck to 1st axle for 3,000 mm

o Gross weight 32,400 kg (4x2 Truck) 38,000 kg (6x2 truck) – Pay load 20,400 kg (4X2 Truck) 25,400 kg (6x2 Truck), Tare Weight 12,000 kg.

o Total length from 13.730 mm to 16.730 mm.

o Low floor length (gooseneck to rear ramps) from 9.730 mm to 12.730 mm

o Width 2.550mm.

o Lower floor length from gooseneck to 1st axle from3,970 mm to 6,970 mm;

o Height of charge zone: from gooseneck to 1st axle 220mm; height between axles chequer plate 450mm; height from 2nd axle to rear ramps 250mm.

o N. 4 wheel troughs placed between axles chequer plate with steel hatches.

o N. 1 Hydraulic pull winch; 8 ton towing force placed on gooseneck with remote control

o Surface treatment: hot dipped galvanized

o Braking system: EBS 4S/2K

o Electric system: 24 volt

o Rear and Front telescopic ramps with hydraulic movements 2400 x 650 mm

o N. 13 tires 205/65 r 17.5 Michelin - Aluminum wheels Speedline make

o N.2 tool boxes on gooseneck

o Warranty program 3 years

Note: those listed are the standard components of this semitrailer; to find out more accessories please visit www.fgmgroup.it and go the configurator section in order to select the options that best satisfy your needs.
